Redfield Revolution 4-12x40mm Riflescope - Matte Finish, 4-Plex / Accu-Range Reticle
Redfield Revolution 4-12x40mm Riflescope - Matte Finish, 4-Plex / Accu-Range Reticle Product information
The Redfield Revolution 4-12x40mm Riflescope is part of the rebirth of an American legend. The Revolution line of Redfield Riflescopes offers an unmatched array of optical, mechanical and functional features in an affordable
price. The Revolution 4-12x40mm Riflescope from Redfield is made in Oregon using state-of-the-art design, manufacturing, assembly, and testing techniques. This Redfield Revolution 4-12x40mm Rifle Scope produces optical, mechanical, and functional superiority that no import can rival. The Illuminator Lens System in this rifle scope combines premium lenses with cutting edge vapor-deposition coatings for best-in-class light transmission in the critical low-light/blue wavelengths most common when game is active. For absolute long-range precision, the available Accu-Range reticle provides hold points to 500 yards with matchless simplicity and deadly accuracy, while meticulous attention to detail generates the ultimate repeatability and reliability of the Accu-Trac adjustment system. Painstaking design effort resulted in Redfield's exclusive Rapid Target Acquisition (RTA) technology, meaning no more missed opportunities because you couldn't find the "sweet spot" behind the scope. And, tested to levels that literally render competitive scopes useless, you can rest assured that your Red Field Revolution Riflescope is absolutely waterproof, fog proof, shock proof, and covered by the Redfield Full Lifetime Warranty. These features of the Red-field Revolution 4-12x40mm Riflescope show why a Redfield Riflescope is quality American craftsmanship at its best, sending the competition home on a slow boat.
Specifications for Redfield Revolution 4-12x 40mm Rifle scope:
| Reticle: | 4-Plex (67110), Accu-Range (67115) |
| Finish: | Matte |
| Lens Coating: | Vapor Deposited, Multi-coated Illuminator Lens System |
| Adjustment Markings: | Accu-Trac 1/4 MOA Finger Click Adjustments |
| Maintube Diameter: | 1" |
| Environmental Protection: | Nitrogen Filled |
| Actual Magnification: | 4.5-11.4 |
| Linear Field of View (ft @ 100yd): | 19.9-9.4 |
| Linear Field of View (m @ 100m): | 6.6-3.1 |
| Exit Pupil (mm): | 8.9-3.5 |
| Weight (ounces): | 13.1 |
| Weight (grams): | 371 |
| Length (in): | 12.3 |
| Length (cm): | 31.2 |
| Mounting Space (in): | 5.6 |
| Mounting Space (cm): | 14.2 |
| Objective Aperture (mm): | 40.0 |
| Eye Relief (in): | 3.7-4.9 |
| Eye Relief (mm): | 124.5-94.0 |
| Elevation Adjustment Range (MOA): | 50 |
| Windage Adjustment Range (MOA): | 50 |
Features of Redfield Revolution 4-12x40 Rifle-scope:
- Made in Oregon
- Resettable stainless steel finger-click Accu-Trac adjustments
- Best in class durability, image quality, and field of view
- Accu-Range reticle for combination of speed & long range precision
- Waterproof, fog proof, shock proof
- Rapid Target Acquisition (RTA) eyepiece
- Lockable eyepiece
- Redfield Full Lifetime Warranty
Package Contents:
- Redfield Revolution 4-12x40mm Riflescope - Matte Finish
Redfield Revolution 4-12x40mm Riflescope - Matte Finish, 4-Plex / Accu-Range Reticle Options
| Product Code | UPC | SKU | Redfield Revolution 4-12x40mm Riflescope - Matte Finish, 4-Plex / Accu-Range Reticle Options |
|---|---|---|---|
| RL-RS-REVO-4-12x40-67110 | 030317671105 | 67110 | Redfield Revolution 4-12x40mm Matte 4-Plex Riflescope |
| RL-RS-REVO-4-12x40-67115 | 030317671150 | 67115 | Redfield Revolution 4-12x40mm Matte Accu-Range Riflescope |
