Leica Geosystems 100t Digitex 8/33, Signal Generator
Tap Tap to Zoom
Product Discontinued by Manufacturer
Leica Geosystems 100t Digitex 8/33, Signal Generator has been discontinued by Leica Geosystems and is no longer available. Our product experts have helped us select these available replacements below.You can also explore other items in the Surveying Equipment Accessories yourself to try and find the perfect replacement for you!
Product Info for Leica Geosystems 100t Digitex 8/33, Signal Generator
The Leica Geosystems Digitex 100T Waterproof Signal Generator 795946 allows users to trace services over a greater distance, improve service detection in areas of high signal interference and improve depth estimation when using a depth locator. This Signal Generator from the experts at Leica Geosystems has four adjustable output levels, delivering a maximum output level of 1 watt. The Leica 100-T Waterproof DigiTex Signal Generation Device is made with a durable waterproof design, that has an environmental protection rating of IP65.
Specifications for Leica Digitex 100 T Signal Generator - Waterproof:
| Operating transmission frequencies: | 8.192kHz; 32.768kHz; Mixed 8/33 (connection mode only) |
| Output power: | 4 levels |
| Induction (Max): | Up to 1W max |
| Direct connection (100 Ohms): | Up to 1W max when connected to a buried service with an impedance of 100 Ohms |
| Battery type: | 4 x D alkaline (IEC LR20), supplied |
| Battery life (Typical use at 20C): | 30hrs intermittent use |
| Weight: | 2.4kg/5.3lbs including batteries |
| Dimensions: | 180mm (H) x 260mm (D) x 280mm (W) |
| IP rating (Case lid closed): | IP65 |
| IP rating (Case lid open): | IP54 |
Features of Leica Digital Signal Generator - Digitex 100t:
- Four adjustable output levels, delivering a maximum output level of 1 watt
- Durable waterproof design, environmental protection rating of IP65
- Robust, compact and lightweight design engineered for tough site conditions
- Choice of 3 tracing signals 33K everyday site use, generally accepted as an
- industry standard
- 8K long tracing and reduced cross coupling
- 8 and 33K (connection mode)
- Ease of use - default output frequency of 33K
- Externally located clear, audio visual controls ensuring a robust waterproof design
- Built-in test function allowing operators to test the hardware and software functionality before use
Package Contents:
- Leica Geosystems Digitex 100T Waterproof Signal Generator 795946
