Product Info for Vortex Strike Eagle 5-25x56mm 34mm Tube First Focal Plane Rifle Scope
Fine-tune your aim and deliver impressive results with your weapon by equipping this Vortex Strike Eagle 5-25x56 FFP Rifle Scope. Vortex built these Riflescopes with waterproof, fogproof and shockproof construction, and the lenses are treated with an ArmorTek coating that protects your glass from scratches, dirt and oil residue. The Vortex Strike Eagle 5-25x56 FFP Rifle Scope creates an easier shooting experience with its throw lever that helps you instantly and quickly change magnification levels. Plus, the fast focus eyepiece greatly increases your target acquisition speed. Mount this Vortex Strike Eagle 5-25x56 FFP Waterproof Rifle Scope to take down targets with incredible efficiency.![]()
Specifications for Vortex Strike Eagle 5-25x56mm 34mm Tube First Focal Plane Rifle Scope:
| Manufacturer: | Vortex |
| Objective Lens Diameter: | 56 mm |
| Magnification: | 5 - 25 x |
| Tube Diameter: | 34 mm |
| Reticle Focal Plane: | First Focal Plane (FFP) |
| Exit Pupil: | 2.24 - 11.2 mm |
| Illumination Color: | Red |
| Finish: | Matte |
| Field of View, Linear: | 5.2 - 24 ft at 100 yds |
| Eye Relief: | 3.7 in |
| Color: | Black |
| Weight: | 30.4 oz |
| Length: | 14.6 in |
| Parallax: | 15 yds to infinity |
| Illumination Type: | LED |
| Battery Type: | CR2032 |
| Width: | 4.5 in |
| Fabric/Material: | Aircraft Grade Aluminum |
| Height: | 3.75 in |
| Lens Material: | XD Glass |
| Optical Coating: | Fully Multi-Coated |
| Brightness Settings: | 11 |
| Water Resistance Level: | Waterproof |
| Shockproof: | Yes |
| Fogproof: | Yes |
| Battery Quantity: | 1 |
| Package Type: | Box |
| Magnification Type: | Variable |
Features of Vortex Strike Eagle 5-25x56mm 34mm Tube First Focal Plane Rifle Scope
- Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications.
- Extra-low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images.
- Provides precise aiming under low-light conditions.
- Patented streamlined design offers a toolless zero stop for rock-solid return to zero after turret adjustments.
- Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
- Anti-reflective coatings on all air-to-glass surfaces provide increased light transmission for greather clarity and low-light performance.
- Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
- Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
- Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
- Low Glare Matte Black Anodize Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position.
- Gas purged and O-ring sealed for fogproof and waterproof performance in all conditions.
- Designed to withstand harsh weather conditions.
- Nitrogen gas purging prevents internal fogging over a wide range of temperatures.
- Designed to withstand the highest levels of impact.
- Allows quick and easy reticle focusing.
- The included throw lever can be installed for quick and easy magnification adjustments.
Package Contents:
- Vortex Strike Eagle 5-25x56mm 34mm Tube First Focal Plane Rifle Scope
- Sunshade
- Lens cloth
- CR2032 battery
- Turret tool
- 2mm hex wrench
- Throw lever
- Rubber style lens covers
- RevStop Zero Ring
